Used Cannabinoid Extraction Machines

Update: November 5, 2024

Ace Spinner ACE-30 1.2

Ace Spinner
Used- Ace Spinner/Curian Ethanol Extractor, Model Ace 30 C1D2. 50 gallon liquid volume and can process 25-30 lbs of milled hemp or cannabis every 20 minutes. The unit has a maximum RPM of 1800 which removes 97% of the ethanol and 98% of the targeted botanicals. The unit has a vacuum jacket allowing for use as a cryogenic extractor.
Manufacturer: Curian
Year: 2019
Serial No.: 8
Info: Pre-Installation Manual
Original Purchase Price: $90,000
Asking Price: $59,999

Solvent Pump 6py53
PUMP,DIAPHRAGM,3/4″

Solvent Pump

Manufacturer: Dayton

Year: 2019

Serial No.: PF01187

Original Purchase Price: $2,100
Asking Price: $1,470

Solvent Pump 6py53
PUMP,DIAPHRAGM,3/4″

Solvent Pump

Manufacturer: Dayton

Year: 2019

Serial No.: PF01192

Original Purchase Price: $2,100
Asking Price: $1,470

Solvent Pump 6py53
PUMP,DIAPHRAGM,3/4″

Solvent Pump

Manufacturer: Dayton

Year: 2019

Serial No.: MF634259

Original Purchase Price: $2,100
Asking Price: $1,470

Solvent Pump 6py53
PUMP,DIAPHRAGM,3/4″

Solvent Pump

Manufacturer: Dayton

Year: 2019

Serial No.: not readable

Original Purchase Price: $2,100
Asking Price: $1,470

Solvent Pump 6py53
PUMP,DIAPHRAGM,3/4″

Solvent Pump

Manufacturer: SC Filtration

Year: 2019

Serial No.: MF634259

Original Purchase Price: $2,100
Asking Price: $1,470

Agilent IDP7 5.4 cfm Oil-Free, Scroll Pump with Deep Vacuum

Vaccumm Pump IDP-7

Agilent IDP7 5.4 cfm Oil-Free, Scroll Pump with Deep Vacuum Feature with exhaust hose and 115v power cord

The Agilent IDP-7 dry scroll pump is an oil-free, compact, quiet, isolated high-performance vacuum pump, suitable for applications in the reseach, analytical instruments, and laboratory markets. It is ideal for situations requiring a compact, table-top pump with greater pumping speed or the ability to handle water vapor.

IDP pumps are hermetic, with the motor and bearings completely isolated from the vacuum path in a design that extends bearing life and provides clean, dry vacuum. IDP pumps use a single-sided scroll design that offers a 15-minute maintenance procedure with simple tools. The optional fail safe isolation valve prevents accidental contaimination and adds no extra height to the pump.

Manufacturer: Agilent

Year: 2019

Serial No.: my19080022

Original Purchase Price: $8,720
Asking Price: $6,104

12.5 Gallon 316 Stainless Steel Dished Bottom Tank

MixerDirect Reactor

12.5 Gallon 316 Stainless Steel Dished Bottom Tank, Dished Top, #4 Inside / 2B
Outside Finish, 316 Stainless Steel Externals, Dimple Jacket
Material Finish
Internal Surface Finish: #4 Sanitary Finish w/ Surface Ground Smooth, Polished &
Buffed
External Surface Finish: 2B Finish w/ Sharp Edges & Weld Discoloration Removed
(weld bead is still visible)
Passivate: None
Top
Top Head: Manway Top, Removable, Rated for 50PSI and FV with White Hypalon
Gasket, 316 Stainless Steel
Mixer Mount: No Bridge or Clamp Bracket; See Fittings Section Below for Flange,
Triclamp or NPT Mounts, As Applicable
Shell
Shell Dims: 16″ Outside Diameter x 16″ Straight Side Height, 316 Stainless Steel,
10 Gage
Shell Volume: 14 Gallons
Baffles: None
Bottom
Bottom Head: Dished, 316 Stainless Steel, 10 Gage
Heating and Cooling
Dimple Jacket for Shell & Dish Bottom Head, 2″ Dimple Spacing, 304 Stainless
Steel, 12″ Jacket Height (as applicable), 1″ NPT Nipple Inlet/Outlet(s), Designed for
50PSI @ 250°F, Surface Area = 838.0in^2, (2) Zone
Internal Pressure Design: 30 PSI at 250°F
ASME Code Stamp: Yes
Insulation: None, See Adder Below

Fittings
2″ Triclamp Mixer Mount in Top Head for Mixer Mount
1″ Triclamp Ferrule in Top Head for Dip Tube
2″ Triclamp Sight Glass, Includes Ferrule, Clamp & Gasket in Top Head for Sight
Glass
2″ Triclamp Sight Glass, Includes Ferrule, Clamp & Gasket in Top Head for Sight
Glass
1/2″ Triclamp Ferrule in Top Head for Condenser
2″ Triclamp Ferrule in Bottom Head for Drain
Supports
Legs: (3) 1-1/2″ Pipe Legs, 316 Stainless Steel
Feet: Bolt Down Flanges
Casters: None
Clearance to the Floor: 12″
Fork Pockets: None
Lifting Lugs: (2) Lifting Lugs
1 HP XP Triclamp Mount Mixer
①Motor: 1 HP, XPFC, Inverter Rated, Class 1, Div 1 Group D, 208-230/460V, 3Ph, 1750
RPM, Bare Wire Leads, 2.3A @ 460V
②Gearbox: None
③Control: None
④Mount: 2” Sanitary Mount, 316SS Wetted/Aluminum & Painted Steel Externals,
Carbon Steel Hardware
⑤Bearing: SS Bearing; Carbon Steel Coupler
⑥Seal: High Performance PTFE Blend Quad Lip Seal Nitrile Anti-Rotation O-Ring,
Sealed for Pressure @ 30psi / Full Vacuum, 250F
⑦Wetted Surface Finish: #4 Food Grade
⑧Shaft: 0.625” x 25” Exposed Length, 17-4 H900 SS, Impeller Welded to Shaft,
Polished to #4 Food Grade Finish
⑨Bottom Impeller: 3.5” High Efficiency Impeller, 3 Blades, Low Shear, 316SS, Welded
Blades, Impeller Welded to Shaft, Polished to #4 Food Grade Finish

Adder: Stainless Clad Insulation for SYS6A4D00013-001
2″ Mineral Wool Insulation Covering Bottom Head and Shell with 14 Gage 304 Stainless
Steel Casing

Original Purchase Price: $12,985
Asking Price: $9,090

12.5 Gallon 316 Stainless Steel Dished Bottom Tank

MixerDirect Reactor 2 SA240 316/316L

12.5 Gallon 316 Stainless Steel Dished Bottom Tank, Dished Top, #4 Inside / 2B
Outside Finish, 316 Stainless Steel Externals, Dimple Jacket
Material Finish
Internal Surface Finish: #4 Sanitary Finish w/ Surface Ground Smooth, Polished &
Buffed
External Surface Finish: 2B Finish w/ Sharp Edges & Weld Discoloration Removed
(weld bead is still visible)
Passivate: None
Top
Top Head: Manway Top, Removable, Rated for 50PSI and FV with White Hypalon
Gasket, 316 Stainless Steel
Mixer Mount: No Bridge or Clamp Bracket; See Fittings Section Below for Flange,
Triclamp or NPT Mounts, As Applicable
Shell
Shell Dims: 16″ Outside Diameter x 16″ Straight Side Height, 316 Stainless Steel,
10 Gage
Shell Volume: 14 Gallons
Baffles: None
Bottom
Bottom Head: Dished, 316 Stainless Steel, 10 Gage
Heating and Cooling
Dimple Jacket for Shell & Dish Bottom Head, 2″ Dimple Spacing, 304 Stainless
Steel, 12″ Jacket Height (as applicable), 1″ NPT Nipple Inlet/Outlet(s), Designed for
50PSI @ 250°F, Surface Area = 838.0in^2, (2) Zone
Internal Pressure Design: 30 PSI at 250°F
ASME Code Stamp: Yes
Insulation: None, See Adder Below

Fittings
2″ Triclamp Mixer Mount in Top Head for Mixer Mount
1″ Triclamp Ferrule in Top Head for Dip Tube
2″ Triclamp Sight Glass, Includes Ferrule, Clamp & Gasket in Top Head for Sight
Glass
2″ Triclamp Sight Glass, Includes Ferrule, Clamp & Gasket in Top Head for Sight
Glass
1/2″ Triclamp Ferrule in Top Head for Condenser
2″ Triclamp Ferrule in Bottom Head for Drain
Supports
Legs: (3) 1-1/2″ Pipe Legs, 316 Stainless Steel
Feet: Bolt Down Flanges
Casters: None
Clearance to the Floor: 12″
Fork Pockets: None
Lifting Lugs: (2) Lifting Lugs
1 HP XP Triclamp Mount Mixer
①Motor: 1 HP, XPFC, Inverter Rated, Class 1, Div 1 Group D, 208-230/460V, 3Ph, 1750
RPM, Bare Wire Leads, 2.3A @ 460V
②Gearbox: None
③Control: None
④Mount: 2” Sanitary Mount, 316SS Wetted/Aluminum & Painted Steel Externals,
Carbon Steel Hardware
⑤Bearing: SS Bearing; Carbon Steel Coupler
⑥Seal: High Performance PTFE Blend Quad Lip Seal Nitrile Anti-Rotation O-Ring,
Sealed for Pressure @ 30psi / Full Vacuum, 250F
⑦Wetted Surface Finish: #4 Food Grade
⑧Shaft: 0.625” x 25” Exposed Length, 17-4 H900 SS, Impeller Welded to Shaft,
Polished to #4 Food Grade Finish
⑨Bottom Impeller: 3.5” High Efficiency Impeller, 3 Blades, Low Shear, 316SS, Welded
Blades, Impeller Welded to Shaft, Polished to #4 Food Grade Finish

Adder: Stainless Clad Insulation for S6A4D00013
2″ Mineral Wool Insulation Covering Bottom Head and Shell with 14 Gage 304 Stainless
Steel Casing

Original Purchase Price: $13,233
Asking Price: $9,263

500 Gallon 304 Stainless Steel Dished Bottom Tank with mixer

Mixer Tank - 500 gal.

500 Gallon 304 Stainless Steel Dished Bottom Tank, Dished Top, 2B-Ground Inside / 2B
Outside Finish, 304 Stainless Steel Externals, ASME Dimple Jacket, Insulated
Material Finish
Internal Surface Finish: 2B-G Finish w/ Welds Ground Smooth, Polished & Buffed
External Surface Finish: 2B Finish w/ Sharp Edges & Weld Discoloration Removed
(weld bead is still visible)
Passivate: None
Top
Top Head: Dished Top, 304 Stainless Steel, 12 Gage
Mixer Mount: No Bridge or Clamp Bracket; See Fittings Section Below for Flange,
Triclamp or NPT Mounts, As Applicable
Shell
Shell Dims: 52″ Outside Diameter x 60″ Straight Side Height, 304 Stainless Steel,
10 Gage
Shell Volume: 551 Gallons
Baffles: None
Bottom
Bottom Head: Dished, 304 Stainless Steel, 10 Gage
Heating and Cooling
Jacket: 304 Stainless Steel, 3.25″ Dimple Spacing, Shell & Dish Bottom Head, 48″
Straight Side Height, Relief Valve In Line By Others, 1-1/2″ NPT Nipples as
In/Outlet
Design: 50 PSI at 250°F, Surface Area = 9353 in2, (2) Zone
ASME Code Stamp: Yes
2″ Mineral Wool Insulation Covering Bottom Head and Shell with 14 Gage 304
Stainless Steel Casing
Fittings
18″ (460mm) Manway w/ Natural Rubber Gasket (<2 PSI @ 194°F) in Top Head for
Entry
4″ Triclamp Mixer Mount in Top Head for Mixer Mount
2″ Triclamp Ferrule in Top Head for Dip Tube (dip tube not included)
2″ Triclamp Ferrule in Top Head for Inlet
2″ Triclamp Ferrule in Bottom Head for Drain

Supports
Legs: (4) 2″ Pipe Legs, 304 Stainless Steel
Feet: Bolt Down Flanges
Casters: None
Clearance to the Floor: 12″
Fork Pockets: None
Lifting Lugs: (2) Lifting Lugs
1HP XP Triclamp Mount Mixer
Motor: 1 HP, XPFC Inverter Duty, Class 1, Div 1, Group C&D; Class 2, Div 1, Group
F&G, Temp Code T4, 10:1 Turndown, 208-230/460V, 3Ph, 1750 RPM, Bare Wire
Leads
Gearbox: Premium Worm Drive, 10:1 Ratio, (175 RPM Output at 1750 RPM Input),
56C NEMA Frame Adapter, Right Angle, Sealed and Maintenance Free, Paint Free
Aluminum, Synthetic Oil
Control: None
Mount: 4” Sanitary Mount, Tapered Recess for CIP, 316SS Wetted/Aluminum &
Painted Steel Externals, SS Hardware
Bearing: SS Bearing; 303 SS Coupler
Seal: FDA Lip Seal, Duralast 4331 Seal w/ Duraloy 5163 Case, Max 3PSI
Continuous
Wetted Surface Finish: 2B Finish
Shaft: 1.25” x 67” Exposed Length, 316SS, No Polish Included
Bottom Impeller: 16” High Efficiency Impeller, 3 Blades, Low Shear, 316SS, Welded
Blades, Deburred, Mill Finish, Keyed w/ Set Screw Attachment

Original Purchase Price: $27,651
Asking Price: $19,356

500 Gallon 304 Stainless Steel Dished Bottom Tank without mixer

Mixer Tank II - 500 gal.

Technical Specification for Part Number: S4ASD00500
500 Gallon 304 Stainless Steel Dished Bottom Tank, Dished Top, 2B-Ground Inside / 2B
Outside Finish, 304 Stainless Steel Externals, ASME Dimple Jacket, Insulated
Material Finish
Internal Surface Finish: 2B-G Finish w/ Welds Ground Smooth, Polished & Buffed
External Surface Finish: 2B Finish w/ Sharp Edges & Weld Discoloration Removed
(weld bead is still visible)
Passivate: None
Top
Top Head: Dished Top, 304 Stainless Steel, 12 Gage
Mixer Mount: No Bridge or Clamp Bracket; See Fittings Section Below for Flange,
Triclamp or NPT Mounts, As Applicable
Shell
Shell Dims: 52″ Outside Diameter x 60″ Straight Side Height, 304 Stainless Steel,
10 Gage
Shell Volume: 551 Gallons
Baffles: None
Bottom
Bottom Head: Dished, 304 Stainless Steel, 10 Gage
Heating and Cooling
Jacket: 304 Stainless Steel, 3.25″ Dimple Spacing, Shell & Dish Bottom Head, 48″
Straight Side Height, Relief Valve In Line By Others, 1-1/2″ NPT Nipples as
In/Outlet
Design: 50 PSI at 250°F, Surface Area = 9353 in2, (2) Zone
ASME Code Stamp: Yes
2″ Mineral Wool Insulation Covering Bottom Head and Shell with 14 Gage 304
Stainless Steel Casing
Fittings
18″ (460mm) Manway w/ Natural Rubber Gasket (<2 PSI @ 194°F) in Top Head for
Entry
4″ Triclamp Mixer Mount in Top Head for Mixer Mount
2″ Triclamp Ferrule in Top Head for Dip Tube (dip tube not included)
2″ Triclamp Ferrule in Top Head for Inlet
2″ Triclamp Ferrule in Bottom Head for Drain
Supports
Legs: (4) 2″ Pipe Legs, 304 Stainless Steel
Feet: Bolt Down Flanges
Casters: None
Clearance to the Floor: 12″
Fork Pockets: None
Lifting Lugs: (2) Lifting Lugs

Original Purchase Price: $23,932
Asking Price: $16,752

Ecosce Omega Mk2

Ecosce MK2

Manufacturer: Ecosce
Year: 2019
Serial No.: Ecosce Omega Mk2 – 500L/hr

The system will process at a volume flow rates up to 500L/hr in this production scale unit.
The benefit of the Ecosce Omega Mk2 is that it is close to ambient temperature process and reduces touch points between miscella and finished product.
The process we envision would be to extract and winterize per your usual method, then run a first pass desolvation using the Mk2. The oil will come out of this process at approximately 1:1 oil to solvent. The remaining solvent can be removed using your preferred technique. It is important to feed only winterized and filtered product into this process to prevent fouling and thus lower production rates.

Original Purchase Price: $313,000
Asking Price: $219,100

300 Gallon Pro Series Reproofing-Still

300 gallon still
300 Gallon Pro Series Still with 16” stainless 16 plate column
300 gallon still
300 Gallon Pro Series Still with 16” stainless 16 plate column
Reproofing-Still

300 Gallon Pro Series Still with 16” stainless 16 plate column
Includes 12” x 72” stainless condenser (NO AGITATOR)
Rite Indoor 63 S 15 HP Low Pressure Steam Boiler—propane fired
Rite indoor CR-50 Condensate Return/Feedwater System
(2) united brass #50 spring loaded check valves
BDT LPS 1648 ASME Code Blowdown tank
Twin tank water softener system
Rite Chemical feed system
Sample cooler installed and piped on the side
Hoffman WC6-20 B Condensate transfer station
Year: 2019
Serial No.: 33551, 33552, A0920

Original Purchase Price: $87,602
Asking Price: $61,321

Single Stage SPD Unit

SciPhy Still
SciPhy Still
Vacuum Pump Leyvac LV80

Manufacturer: SciPhy
Year: 2019
Serial No.: JSI-190402

Specifications for Single-stage 0.1m2 SPD System

1. Feedstock tank
Feedstock tank: 50L, without an agitator
With jacket for hot oil heating
All necessary valves and instruments
2. Short path Distiller
Type: SPD
Evaporator surface: 0.1m2
Internal diameter of the internal evaporator body: about 125mm
Heating fluid for evaporator: Hot oil 250 °C
(actual work temp: 200 °C)
Cooling fluid for internal condenser: Cooling water (Tempered)
Wiping system, removable: roller wiper system
Rotary transmission: double mechanical sealing
Wiper type: Roller wiper, one set of Roller Wipers to be equipped on the
machine
3. Cold trap: 0.22 m2
Heat Exchange surface: 0.22m2
4. Receiver tanks for SPD
Two receiver tanks for receiving heavy-phase components and light-phase
components
One heavy-phase receiver tank with jacket, 5L, with sight glass and level gauge
One Light-phase receiver tank with jacket, 5L, with sight glass and level gauge
5. Distillate product discharge gear pump with variable speed control
Equipped with ABB motor, power: 0.37KW, the pump is with jacket heating
Flow range: 3~20L/h, temp range: -30~250 Deg C
All necessary valves and instruments
6. Residue discharge gear pump with variable speed control
Equipped with ABB motor, power: 0.37KW, the pump is with jacket heating
Flow range: 3~20L/h, temp range: -30~250 Deg C
All necessary valves and instruments
7. Piping
All necessary product and vacuum piping will be supplied within skid
Cooling water to condenser will be provided and connected by customer
8 . Vacuum System for SPD consisting of the following:
Vacuum line to the cold trap #2
Cold trap cooled: 0.22m ²
WAU501 FP LeyBold Roots vacuum pump
LV80 Leybold Dry screw vacuum pump
Direct Mounted WAU501 FP: pumping rate: 607 m ³ /h @60 Hz, ultimate
pressure: 6.7 x 10 ⁻² mbar (5 x 10 ⁻² Torr ) , motor power: 2.2KW, rotation
speed:
7200 rpm
Dry screw vacuum pump LeyBold LV80: 80 m ³ /h, ultimate pressure: 1 x 10⁻²
mbar , motor power: 3.2kW, water-cooled, cooling water consumption: 180 L/hr
Voltage: 3-ph, 380/480 V, 50/60 Hz1
9. Control box
A small control box for manual controls, will include frequency inverter and
manual ON/OFF switches.
10. The Warm Water Circulation System
· Delta-T Single zone water circulating temperature control system
· Compact, space saving, cast design
· Heavy gauge, powder coated sheet metal cabinet
· All components easily accessible for servicing when required
· Suitable for operation up to 250°F (121°C)
· NPT water supply and drain connections
· 1.5” NPT delivery and return connections
· Direct injection cooling circuit
· 3” heavy duty industrial grade casters (2 swivel, 2 stationary)

 Original Purchase Price: $96,350
Asking Price: $67,445

CryoDax 16 Water-Cooled Chiller/Heater 1CD16W

CryoDax 16

Manufacturer: Mydax
Year: 2019
Serial No.: 120-1573

CryoDax 16 Water-Cooled Chiller/Heater

Standard Specifications and Features
• Fluid Setpoint Range -70°C to +80°C
• Temperature Stability ± 1.0°C
• Net Cooling Capacities 13.1 kW at -30°C
8.0 kW at -40°C 4.7 kW at -50°C
2.2 kW at -60°C 900 W at -70°C
(*Ratings on 60 Hz with standard pump)
• Nominal Heating Capacity 3,000 Watts
• Recirculating Flow/Pressure 4 Gpm at 25 PSI,
2 Gpm at 45 PSI
• Stainless Steel Reservoir 5 Gallons (vented)
• Recirculating Fluid Syltherm HF or XLT
• Recirculating Supply/
Return Fittings 3/4″ Stainless Steel FNPT
• Facilities Requirements Up to 12 Gpm at 70°F inlet,
20 Psi ΔP
• Facilities Supply/
Return Fittings 1” Stainless Steel FNPT
• Electrical Service 440/480 VAC, 60 Hz, 3 phase,
50 amp service
• Physical Parameters 66″ H x 36″ W x 50″ D,
1050 lbs dry weight approx.
• Warranty 12 Months, Parts and Labor
• Refrigeration 16 Hp semi-hermetically sealed compressor,
R-507 refrigerant
• Condenser Brazed plate heat exchanger with a
water flow control valve to automatically maintain condensing temperature
• Recirculation 1.5 Hp SS seal-less magnetic-drive turbine
pump, turbine fluid flowmeter in recirculating
return, pressure gauge, overpressure switch, brazed plate heat exchanger, copper piping
• Safety Fluid low level and empty switches,
Interlocks refrigerant high and low pressure switches,
fluid over-temperature switch, emergency
off switch
Please contact Mydax to customize this system for your specific needs
Patents: #4,742,689, #4,959,972, #4,934,155
• Controller PID type controller with a 5.7″ color
graphic touch-screen display providing
fully proportional cooling and heating
with the Mydax patented refrigeration circuit
• Interfacing Remote contacts providing run and
alarm status, RS-232 serial interface
for remote control and monitoring
• Construction Welded steel frame with aluminum
panels, frame and panels are powder
coated for durability, mounted on
locking casters and leveling feet
• Safety Refrigeration Standard AHRI 550/590,
Standards National Electrical Code NFPA-70,
Electrical Standard for Industrial
Machinery NFPA-79

 Original Purchase Price: $71,050
Asking Price: $49,735

Legacy Chiller PZAPT4SH5

Legacy Chiller PZAPT4SH5

Manufacturer: Legacy
Year: 2019
Serial No.: 19FO2198

!!!Needs Technical Support!!!The communication between the panel and controller has to be fixed! Call for service.

Legacy – MO# PZAPT4SH5 Liquid Chiller Package
with internal plastic tank with SCROLL
compressor(s). NOTE: Tank is plumbed as buffer
system.
System performance capability: MO# PZAPT4SH5
Air-cooled condenser @ 45F leaving water temp @
95F outdoor ambient temperature will provide
43200 BTUH.
Base platform description: Self-contained package
fluid chiller, 460-3-60, R407C, air-cooled condenser.

Original Price: $8,592
Asking Price: $5,155 (40% Off)

Delta T System Air Cool Chiller VSPA-008

Delta T System Air Cool Chiller VSPA-008

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 21891

Delta T Systems Model VSPA-008
Variable Speed, Portable Air Cooled Chiller
GENERAL UNIT OVERVIEW
 7.5 ton air cooled chiller
18 GPM at 35 PSI pump/motor; 1 Hp
Footprint of 34W” x 34D” x 74.5H”
Wired for 3/60/460; MCA 15.51
Full featured unit: variable speed compressor and fan motor, electronic expansion valve,
±0.5º F temp control, 0º-80º F temp range.
1.5 Hp pump (18 GPM @ 51 PSI)

Original Purchase Price: $15,275
Asking Price: $10,693

Delta -T System Heater – water KF431

Delta -T System Heater - water

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 22207

Original Purchase Price: $2,765
Asking Price: $1,934

Delta – T System Heater – oil T 1021MS

Delta - T System Heater - oil Model T1021MS

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 21764

UNIT OVERVIEW

Single zone oil circulating temperature control system
Upright, operator convenient design
Heavy gauge, powder coated, sheet metal cabinet
All components easily accessible for servicing when required
Suitable for operation up to 550°F (287°C)
1” NPT delivery and return connections
Heating only capability
3” Heavy duty industrial grade casters (2 swivel, 2 stationary)
5.5 gallon expansion/reservoir tank
Y-strainer on return line to keep circulating fluid clean

PUMP SPECIFICATIONS
Positive displacement, mechanical seal circulating pump
¾ HP 3 phase motor
10 GPM @ 30 PSI pumping capacity

MECHANICAL FEATURES
12 KW heating capacity using low watt density, steel sheath heater elements
Fully insulated heater tank to maximize heating efficiency
“To process” system pressure gage
“Fulflo” bypass valve, to protect the heating elements and pump
Highly visible system status indicators:
o Power – on, Heating – on

ELECTRICAL/SAFETY SPECIFICATIONS
Fused motor and heater protection
Fuse transformer protection on both primary and secondary sides
Grounded control circuit
Motor overload protection
High temperature safety thermostat protection
Non-fused disconnect switch
NEMA 1 electrical specifications and NEC electrical code conformance
UL, CSA, CE recognized and listed electrical components
Wired 3/60/460

CONTROLLER FEATURES
Fully programmable to provide versatility and control flexibility
Bright easy-to-read LED display
“Positive feel” control buttons
Full feature “autotune” capability
Included Options:
1/8 DIN ATHENA MODEL 18C-4/20MA W/ AUTO VENT
Pump reverse with manual drain
Touch Safe Electronics (covers over electrical components)
Paratherm NF®, our recommended heat transfer fluid, 55 gallon drum

Original Price: $10,637
Asking Price: $7,446

Delta – T System Heater – oil T 1021MS

Delta - T System Heater - oil T 1021MS

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 21745

UNIT OVERVIEW

Single zone oil circulating temperature control system
Upright, operator convenient design
Heavy gauge, powder coated, sheet metal cabinet
All components easily accessible for servicing when required
Suitable for operation up to 550°F (287°C)
1” NPT delivery and return connections
Heating only capability
3” Heavy duty industrial grade casters (2 swivel, 2 stationary)
5.5 gallon expansion/reservoir tank
Y-strainer on return line to keep circulating fluid clean

PUMP SPECIFICATIONS
Positive displacement, mechanical seal circulating pump
¾ HP 3 phase motor
10 GPM @ 30 PSI pumping capacity

MECHANICAL FEATURES
12 KW heating capacity using low watt density, steel sheath heater elements
Fully insulated heater tank to maximize heating efficiency
“To process” system pressure gage
“Fulflo” bypass valve, to protect the heating elements and pump
Highly visible system status indicators:
o Power – on, Heating – on

ELECTRICAL/SAFETY SPECIFICATIONS
Fused motor and heater protection
Fuse transformer protection on both primary and secondary sides
Grounded control circuit
Motor overload protection
High temperature safety thermostat protection
Non-fused disconnect switch
NEMA 1 electrical specifications and NEC electrical code conformance
UL, CSA, CE recognized and listed electrical components
Wired 3/60/460

CONTROLLER FEATURES
Fully programmable to provide versatility and control flexibility
Bright easy-to-read LED display
“Positive feel” control buttons
Full feature “autotune” capability
Included Options:
1/8 DIN ATHENA MODEL 18C-4/20MA W/ AUTO VENT
Pump reverse with manual drain
Touch Safe Electronics (covers over electrical components)
Paratherm NF®, our recommended heat transfer fluid, 55 gallon drum

Original Price: $10,637
Asking Price: $7,446

Delta – T System Heater – water AD431S

Delta -T System Heater - water AD431S

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 21775

Delta T Systems Temperature Control Unit
Accent Series

GENERAL UNIT OVERVIEW
Full featured water temperature control unit designed for
continuous, reliable service
9 kW single zone temperature control
¾ hp, 25 gpm at 25 psi centrifugal pump/motor
3/60/460V electrical service
250° F max operating temperature
Microprocessor based, PID controller, 1/16th DIN

STANDARD FEATURES
Mechanical Features
Compact, space saving cabinet with heavy gauge, powder coated sheet metal
construction
Heavy duty 3” industrial grade casters (2 swivel, 2 stationary)
Centrifugal pump, 3 phase motor, non-overloading
Stainless steel motor shaft
Long life silicon carbide high temperature seal
Incoloy sheathed, low watt density heater element
Fully insulated tank to maximize heating efficiency
Automatic vent sequence with vent button to purge the process loop
Liquid filled Delivery and Return pressure gauges
Highly visible system status indicators:
o Cooling –on
o Low water pressure
o Power – on
o Heating – on
Direct injection cooling method; cooling solenoid integral to the drain line
Safety relief valve, protects the process loop from high pressure
Safety thermostat protection programmed into the PID controller
Safety pressure switch, protects unit from running without cooling water

Controls and Electrical Features
Fully programmable microprocessor based PID controller, designed to provide versatility
and control flexibility
Motor circuit interrupter protection
Fuse protection on primary and secondary side of the control transformer
Grounded control circuit
NEMA 1 electrical specifications and NEC electrical code conformance
UL, CSA, CE recognized and listed electrical components

Original Price: $2,425
Asking Price: $1,698

Delta – T System Heater – water AD431S

Delta -T System Heater - water AD431S

Manufacturer: Delta T Systems
Year: 2019
Serial No.: 21776

Delta T Systems Temperature Control Unit
Accent Series

GENERAL UNIT OVERVIEW
Full featured water temperature control unit designed for
continuous, reliable service
9 kW single zone temperature control
¾ hp, 25 gpm at 25 psi centrifugal pump/motor
3/60/460V electrical service
250° F max operating temperature
Microprocessor based, PID controller, 1/16th DIN

STANDARD FEATURES
Mechanical Features
Compact, space saving cabinet with heavy gauge, powder coated sheet metal
construction
Heavy duty 3” industrial grade casters (2 swivel, 2 stationary)
Centrifugal pump, 3 phase motor, non-overloading
Stainless steel motor shaft
Long life silicon carbide high temperature seal
Incoloy sheathed, low watt density heater element
Fully insulated tank to maximize heating efficiency
Automatic vent sequence with vent button to purge the process loop
Liquid filled Delivery and Return pressure gauges
Highly visible system status indicators:
o Cooling –on
o Low water pressure
o Power – on
o Heating – on
Direct injection cooling method; cooling solenoid integral to the drain line
Safety relief valve, protects the process loop from high pressure
Safety thermostat protection programmed into the PID controller
Safety pressure switch, protects unit from running without cooling water

Controls and Electrical Features
Fully programmable microprocessor based PID controller, designed to provide versatility
and control flexibility
Motor circuit interrupter protection
Fuse protection on primary and secondary side of the control transformer
Grounded control circuit
NEMA 1 electrical specifications and NEC electrical code conformance
UL, CSA, CE recognized and listed electrical components

Original Price: $2,425
Asking Price: $1,698

Vacuum Pump Rocker 801

Vacumm Pump 801

Manufacturer: Rocker
Year: 2019
Serial No.: 167801-11-BABB034

  • Model number: Rocker801
  • Discharge flow rate (50/60Hz): 67/80L/min
  • Achieving pressure: 12kPa
  • Connection port size: 8mm
  • Noise: 68dB
  • Power supply: 110V +/-10% 220W
  • Outlet shape: 3P (without conversion plug)
  • Power cord length: 1.7m
  • Size: 346 x 175 x 200mm
  • Weight: 7.9kg
  • Accessories: Trap, regulator

Original Purchase Price: $899
Asking Price: $629

HPLC Interchim ITM-800 Gen.5

itm-800 gen5
Interchim ITM800 Gen5

Manufacturer: Interchim
Year: 2019
Serial No.: 1566-P and 1566-UC

ITM800 Gen5, 800 ml/min, 10 bar, UV
200-400nm, 6 x 1 L Flasks
AX-MJRP/200 Interchim MJRP Axial Compression Column, 400 x 200 mm
EA FJ4331 PuriFlash Collector Rack, Funnel Rack
KIT FV1290 Ballasting kit for 3/16″ tubing
5FT PF150 Tygon Tubing, FEP lined, 3/8″ ID

CBD purification is achieved using reverse phase flash
chromatography. The bench-top unit supports this
technique with ease and simplicity. The large touch
screen interface displays all operating parameters of
the method in progress. A UV diode array detects the
cannabinoids which are collected in 1 liter flasks or
diverted to high capacity carboys with a funnel rack.
In this example a 180 gram hemp distillate (80% CBD)
sample is purified in under 40 minutes.
Pilot and process scale instruments are built to specification
and utilize axial compression columns with inner
diameters up to 1.2 meter.
Interchim is a well established manufacturer of low and
high pressure chromatography instruments. The company
was founded in 1970 to manufacture innovative
products for pharmaceutical R&D. Years of experience
have been applied to provide the cannabis market with
a simple and cost effective purification solution.

ITM-800, 20 cm Column
Load per Run 700 g
Load per Day 19.6 kg
CBD Output 11.8 kg

Original Price: $180,439
Asking Price: $126,307

HPLC Shimadzu LC2030-C

HPLC Shimadzu

Manufacturer: Shimadzu
Year: 2019
Serial No.: L21445650239US

The Shimadzu i-Series HPLC systems help users to improve their workflow with automation, high throughput, ecological features and compatibility with mobile devices while maintaining adaptability with existing methods for easy transfer. In addition to the uncompromised efficiency and quality of analysis, operators benefit from intuitive operation of the color touch panel, remote monitoring and control by smartphone or tablet PC as well as advanced startup and shutdown functions. These features make the i-Series family an intelligent instrument which fits both large labs requiring high throughput operation as well as small labs with limited bench space. The i-Series increases productivity, e.g. in R&D, quality control and safety testing, while minimizing operator workload, cost of ownership and environmental impact.

This model includes a sample cooler and a UV detector. It is previously used for cannabis potency analysis.

Original Price: $48,444
Asking Price: $33,911

Ethos X Microwave Green Extraction of Natural Products

Microwave Ethos-X Terpenes
Microwave Ethos-X Terpenes

Solvent-free approach to high quality extraction

The analytical procedure for flavors and fragrances extraction from plants or spices comprises two steps: extraction by steam distillation or hydro-distillation, and analysis by GC or GC-MS. While the analysis step requires just few minutes, extraction takes several hours, using a standard procedure based on the Clevenger (1928 year!).
To address these limitations, Milestone has developed the new ETHOS X for the solvent-less extraction of natural products. ETHOS X utilizes a unique microwave selective heating mechanism. The internal water within the sample absorbs microwaves and heats up, distending the sample’s cells and rupturing the glands and oleiferous receptacles. This process evaporates the in-situ water within the plant material to quickly extract the desired oils
  • Fast and solvent-free extraction
  • High extracts purity
  • No thermal degradation
No clean up

Original Price: $40,540
Asking Price: $28,378

6′ Protector Premier Laboratory Hood, 208-230V, 50/60Hz

6' Protector Premier Laboratory Hood, 208-230V, 50/60Hz

These hoods are suitable for providing personal protection needed for general chemistry applications involving fumes and vapors. They meet the SEFA-1 standard of a low velocity, high performance hood and may be safely operated as low as 60 fpm. Choose from hoods designed to be used with a remotely-located blower or hoods that include a built-in blower — the only high performance hood with built-in blower available anywhere. Explosion-proof hoods with built-in blower are available for laboratories with potentially explosive/flammable atmospheres (Class 1 Div I or II).

Attributes

  • Product Subcategory: General Chemistry
  • Nominal Width: 6′
  • Blower Requirements: Remote blower required
  • Conformance: ANSI Z9.5, ASHRAE 110, ASTM E84, CAN/CSA C22.2, CE, NFPA 45, SEFA 1, UL
  • Enclosure Height: 59.0″
  • Exterior Depth: 31.7″ (80.5 cm)
  • Lighting: LED
  • Style: Benchtop

Specifications

  • Estimated Shipping Weight: 485.0 lbs
  • Estimated Shipping Weight metric: 220.0 kg
  • Dimensions: 72.0″ w x 31.7″ d x 59.0″ h
  • Dimensions metric: 182.9 x 80.5 x 149.9 cm
  • Electrical: 208-230 volts, 50/60 Hz, 5 amps

Original Price: $19,448
Asking Price: $13,614

Kore Compressor SCR25M-8

Kore Compressor SCR25M-8
Kore Compressor SCR25M-8

Compressor World 25-hp rotary screw air
compressor, 107-cfm @ 125-psi, 230/460
electrics, 460/3/60 volt
– Sound Enclosure
– PLC Controller
– Wye Delta Reduced Voltage Starting
– Phase Protection
– TEFC Drive Motor
– Air Cooled After Cooler

Original Price: $8,900
Asking Price: $6,230

3 Compartment Sink

3 Compartment sink

Stainless Steel

Year: 2019

High Temp Dishwasher HT-180

HT 180 Dishwasher

This Noble Warewashing HT-180 high temperature dishwasher is operation-ready with all the features you need to properly wash and sanitize your glassware and dinnerware.

With a 57 second normal washing cycle, 17 1/4” door opening, and 1 hp wash pump, the Noble Warewashing dishwasher can clean up to 58 standard dish racks per hour. This unit uses just 0.89 gallons of water per cycle, making it economical to operate and friendly to the environment. A built-in 12.9 kW, 70 degree rise booster heater and Sani-Sure feature ensure proper rinse water temperatures and effective sanitizing. In addition, specially designed stainless steel nozzles provide superior cleaning action while preventing clogs.

Other helpful features of the Noble Warewashing HT-180 high temperature dishwasher include top-mounted controls for easy operation, and 4 selectable wash cycles (Normal, Medium, Heavy, Extra Heavy). A front dress panel and safety door switch combine to make this machine safe for all users. The heavy-duty stainless steel construction resists corrosion and adds extended durability.It requires a 208/230V, 1 phase electrical connection.

Overall Dimensions:
Left to Right: 25 1/4″
Front to Back: 25 1/4″
Height: 64 3/8″

Original Price: $5,889
Asking Price: $4,122

FX28-2 Shel Lab Forced Air Oven, 27.8 Cu.Ft. 220V

FX28-2 Shel Lab Forced Air Oven, 27.8 Cu.Ft. 220V

OVEN, FORCED AIR, 27.5 CU FT, DIGITAL WITH TIMER, 230V The SHEL LAB Model SMO28-2 is the largest general purpose oven on the market (also consider the SMO34HP-2 or SMO38HP-2 high performance ovens for the best uniformity and functionality). The independent overtemperature safety feature is user adjustable and provides added safety. The turbo blower-assisted forced airflow design coupled with a heavy-duty blower motor offers excellent temperature uniformity and fast recovery times. Airflow is directed evenly across all shelves and samples to ensure consistent drying, curing and baking results. These units are especially ideal for glassware drying in core facilities. More information available at www.shellab.com

Original Price: $6,150
Asking Price: $4,305

Harter – German Box Dryer – Pharmaceutical Grade

Harter Drying Box
Harter Box Dryer
Harter Box Dryer
Harter Box Dryer
Harter_Floor Drying Box_19.05.27_Aufstellung komplett_Seite_1
Harter_Floor Drying Box_19.05.27_Aufstellung komplett_Seite_1
Harter_Floor Drying Box_19.05.27_Aufstellung komplett_Seite_1

Bulk density: approx. 200 kg/m³ (moist product)
Input per batch: ~ 2700 kg
= dried product per batch: ~ 578 kg
Drying time per batch: ~ 24 h
Product moisture before drying: 80%
Product moisture after drying: < 8%
Moisture input of product: ~ 2122 L/batch
Fill depth level: approx. 500 mm (modus floor drying)
Drying temperature: to be determined by the customer
Temperature range without heatpipe: 10 – 60°C
Dehumidification power 2x Airgenex: approx. 2x 45 l/h (at air temperature of 25°C and
degree of saturation of return air at 50%rF)
Air routing in chamber: vertically

Original Price: $316,765
Asking Price: $221,735

Belt Dryer – GX 12

GX 12
Belt Dryer
Riello RS50E
GX12specs

GX-12 Mesh Belt Drying

Raw material:Hemp flower and leaves
Fuel: natural gas
Input Capacity:400-500kg/h(=890-1000pounds /h), based on temperature 90 fahrenheit.
Input moisture:85%, output moisture:8-12%.
The drying machine can adjust from 0-120 degree centigrade.
Purpose: Extraction cbd

Inclusive Riello Burner
RIELLO RS50/E PROPANE GAS BURNER
– MAX OUTPUT = 2201 MBH MINIMUM OUTPUT = 321 MBH
– 460/3/60 FAN MOTOR
– UV Scanner, Alram horn with silencing switch, dry contacts for burner status and alarm
– Indicating Lighes for Power On, Ignition, Fuel On, Alarm and Call for Heat
– up to 7:1 turn down capability with correct conditions
– Siemens LMV37 flame safe guard with UV scanner,
– Linkageless, digital gas valve controller
– Linkageless, digital combustion air damper controller
– OCI Kit ModBus communications capable
– Siemens RWF55 modulating controller for local/automatic operation
– Local/Remote control switch (for control via lead/lag panel or BAS future)
– Control Circuit Transformer
– SIEMENS GAS TRAIN Pre-Piped for 8-14″ WC inlet gas pressure
– Air NI 1000 RTD 1/2″ NPT x 12″ Temperature Sensor (for field installation)

Original Price: $81,800
Asking Price: $57,260

Schutte-Buffalo 1320 Hammer Mill

1320 Hammer Mill
1320 Drawing

40 HP, TEFC, 3/60/460/3600 rpm motor, direct connected with guard.

Mill manufactured from ½” A-36 plate, mounted to a structural steel sub-base.

Screens that lock in place for perfect fit – two screens provided

Heavy-duty, statically, and dynamically-balanced rotor assembly with:

3/8” standard notched heat-treated hammers

3/4” diameter heat-treated hammer rods

Precision machined shaft warranted for five (5) full years

1/4” rotor discs

Grease lubricated ball bearings – 2 7/16”

Magnet mounted on infeed table

Safety interlock package

40 HP Variable Speed Drive (460V)

Carbon Steel Support Stand to Elevate Mill

Discharge collection bin (carbon or stainless), with dust collector, fittings and hoses.  Local control for dust collector.

Inclusive:
DISCHARGE AUGER 304SS
9″ DIAMETER
U-STYLE
10FT LONG WITH 2HP VFD
CARBON STEEL SUPPORT STAND

Original Price: $54,095
Asking Price: $37,867

Astell 125 Liter Square Eco Steam Sterilizer – Brand New

Autoclave
Autoclave
Autoclave

The Square-Eco range is the perfect research grade square-chambered autoclave. These units can sterilise almost all autoclavable material used in the laboratory – from instruments and glassware, to discard and liquids. They cannot dry fabric, and have a manual door, which make them our simplest square-chambered autoclaves. Ranging from 125 to 360L, the Square-Eco provides the usability of a square chamber autoclave at a fraction of the price. This range is designed with price and economy in mind – the Square-Eco range offers all the functionality of Astell’s standard circular range of autoclaves, but with increased usable capacity due to a square chamber design. They are designed to be water efficient, with Autofill and Autodrain options fitted as standard, and low in power consumption by utilising 16kW heaters in chamber across the range.

  • Steam generated by heaters in chamber
  • 316 stainless steel electropolished chamber
  • Assisted air cooling
  • Autofill and autodrain
  • Media holdwarm and delayed start facility
  • External pressure gauge
  • Assisted air cooling
  • Timed/pulsed freesteaming
  • 5.7 inch colour touchscreen controller
  • Cooling lock
  • Electrically heated steam generators
  • Five password levels to stop lower level users making changes
  • Five pre-programmed cycles and up to 50 available
  • Single manual upwards sliding door
  • Optimised for low water and power consumption
  • Over temperature protection
  • Temperature range of 100 to 138°C (0.2 – 2.4 Bar)
  • Timed/pulsed free steaming
  • Fully programmable 5.7″ colour touch screen controller
  • Validation port
  • Requirements: cold water supply of 2-6 Bar minimum, 4 litres/min is required, max temperature 25°C, max flow rate 20 litres/ min. Drainage: Free venting, non-manifolded drain (54mm diameter) capable of withstanding temperatures up to 100°C. Power supply: 460V, 3 Phase, Neutral & Earth, 16kW

Original Price: $40,833
Asking Price: $28,583

CenturionPro HP3 TRIPLE BUCKER (STAND INCLUDED)

HP3 TRIPLE BUCKER (STAND INCLUDED)<br />
HP3 TRIPLE BUCKER (STAND INCLUDED)<br />

At $10,995 USD, the HP3 Triple Bucker provides triple the production capacity of the HP1, resulting in the industry’s highest buck rate per hour. This bucker utilizes two rollers per workstation that pull the stem into the machine, therefore popping the flowers off.

Complete with three workstations, the HP3 Triple Bucker is a multi-operator run industrial de-stemming machine that requires 3 operators for optimal speed and efficiency. Each workstation has 5 different sized holes to provide versatility and improve processing capacity. The HP3 Triple Bucker accepts stems up to 3/4” in diameter and can process up to 500 lbs wet (up to 100lbs dry) per hour of use. This triple-headed machine comes with a bucker stand included for added value and ease of de-stemming. The bucker stand comes standard with industrial casters.

When combined with the high productivity of a CenturionPro trimming machine, you’ll get the highest capacity harvesting system in the world! The HP3 Triple Bucker comes complete with three 0.75 HP gear driven motors with a variable speed controller to provide unsurpassed power, adjustability and control. Thanks to the variable speed controls, wet or dry product can be processed with ease! The system is easy to set up and is made of stainless steel and anodized aluminum making it robust as well as easy to clean. The HP3 Triple Bucker plugs into a 110 volt, 20 amp circuit – EU/AUS compatible. Backed by a 10 years warranty.

The HP3 Triple Bucker is quickly making a name for itself as the highest capacity bucker in the world! This bucker is simple, powerful and effective and will process product at an unprecedented rate.

Original Price: $10,995
Asking Price: $7,697

CenturionPro HP1 BUCKER (STAND INCLUDED)

HP1 BUCKER (STAND INCLUDED)<br />
HP1 BUCKER (STAND INCLUDED)<br />

At $5,495 USD, the HP1 comes with a bucker stand and table-top set-up legs included for added value and versatility.  With 5-hole sizes, the HP1 accepts wet or dry stems up to 3/4” and can process up to 175 lbs wet (up to 35 lbs dry) per hour, replacing 5-7 human workers. When combined with the high productivity of the CenturionPro trimming machines, you’ll get the highest capacity harvesting system in the world! The HP1 comes complete with a 0.75 HP gear driven motor with variable speeds to provide unsurpassed power and adjustability. Thanks to the variable speed controls, both wet and dry products can be processed with ease! The system is easy to set up and is made of stainless steel and anodized aluminum making it robust as well as easy to clean. The HP1 plugs into a 110-volt, 15-amp circuit – EU/AUS Compatible (Not GFCI Compatible). Backed by a 10 years warranty. The HP1 bucker is simple, powerful, and effective and will process product at an unprecedented rate.

The bucker stand comes standard with industrial casters.

Original Price: $5,495
Asking Price: $3,847

Toyota 8FGU25

CenturionPro HP1 BUCKER (STAND INCLUDED)

Toyota 8FGU25

Example Photo – LP Fuel!

MAKE: TOYOTA
MODEL: 8FGU25
SERIAL NUMBER: 18937
HOURS: 4000
MAST: 189” RAISED
SIDE SHIFT: YES
CAPACITY: 5,000
POWER: LP Fuel
FORKS: 48”
VALVES: 3
TIRES: SOLID PNEUMATIC
ATTACHMENT: SIDE-SHIFT
YEAR: 2008

Asking Price: $16,800

Get in Touch

If you are interested in our used cannabinoid extraction machines, we would love to hear from you! Please fill out the form below to submit your offer or inquire about our equipment. Alternatively, you can email your offer directly to rgrodde@hotmail.com. We look forward to assisting you with your purchase.

Limited-Time Opportunity

Don’t miss out on this exclusive chance to acquire top-quality cannabinoid extraction machines at unbeatable prices. These machines, previously used by New Mexico Hemp Services LLC, are available for a limited time only. Act now and submit your offer today to secure these exceptional deals!
